1973 Cessna Centurion T210L
1973 Cessna Centurion T210L Base price: $544,295 Engine make/model: Continental TSIO-520H TBO (hrs.): 1400 Horsepower@altitude: 285 to 17,000 ft. Horsepower on takeoff: 285 Fuel type: 100/100LL Propeller type: McCauley CS/3-blade…
|
||
1973 Cessna Centurion T210L
|
||
Base price: | $544,295 | |
Engine make/model: | Continental TSIO-520H | |
TBO (hrs.): | 1400 | |
Horsepower@altitude: | 285 to 17,000 ft. | |
Horsepower on takeoff: | 285 | |
Fuel type: | 100/100LL | |
Propeller type: | McCauley CS/3-blade | |
Landing gear type: | Tri./Retr. | |
Max ramp weight (lbs): | 3800 | |
Gross weight (lbs.): | 3800 | |
Landing weight (lbs.) | 3800 | |
Empty weight, std. (lbs.): | 2195 | |
Useful load, std. (lbs.): | 1605 | |
Useful fuel, std (gals.): | 89 | |
Payload, full std. fuel (lbs.): | 1071 | |
Wingspan: | 36 ft. 9 in. | |
Overall length: | 28 ft. 3 in. | |
Height: | 9 ft. 7 in. | |
Wing area (sq. ft.): | 175.1 | |
Wing loading (lbs./sq.ft.): | 21.7 | |
Wheel size (in.): | 6.00 x 6 | |
Power loading (lbs./hp): | 12.3 | |
Seating capacity: | 6 | |
Cabin doors: | 2 | |
Cabin width (in.): | 45.5 | |
Cabin height (in.): | 48 | |
PERFORMANCE
|
||
CRUISE SPEED (kts.): | ||
80% power: | 198@20,000 ft. | |
70% power: | 190@20,000 ft. | |
FUEL CONSUMPTION (gph.): | ||
80% power: | 17.2 | |
70% power: | 15.5 | |
RANGE (plus reserve, nm): | ||
80% power: | 830 | |
70% power: | 880 | |
Vso (kts.): | 57 | |
Best rate of climb, SL (fpm): | 1115 | |
Service ceiling (ft.): | 28,500 | |
Takeoff distance (ft.): | 1170 | |
Takeoff over 50 ft. obstacle (ft.): | 2030 | |
Landing distance (ft.): | 765 | |
Landing over 50 ft. obstacle (ft.): | 1500 | |
Source: Jane's All The World's Aircraft and Intertec's Aircraft Bluebook Price Digest | ||
