Piper 1997 Seneca V

Piper 1997 Seneca V

Base/used Price:

$519,900

Engine make/model:

Continental TSIO-360-RB

Horsepower@altitude:

220

Horsepower for takeoff:

220

TBO hrs.:

1800

Fuel type:

100/100LL

Propeller type/diameter:

Hartzell CS

Landing gear type:

Tri/Retr.

Max ramp weight (lbs.):

4773

Gross weight (lbs.):

4750

Landing weight (lbs.):

4513

Empty weight, std. (lbs.):

3413

Useful load, std. (lbs.):

1337

Payload, full std. fuel (lbs.):

605

Usable fuel, std. (gals.):

122

Wingspan:

38 ft. 10 in.

Overall length:

28 ft. 7 in.

Height:

9 ft. 11 in.

Wing area (sq. ft.):

209

Wing loading (lbs./sq. ft.):

22.7

Power loading (lbs./hp.):

10.8

Wheel base:

7 ft.

Wheel track:

11 ft. 1 in.

Wheel size (in.):

6.00 x 6

Seating capacity:

6

Cabin doors:

2

Cabin width (in.):

49

Cabin height (in.):

47

Baggage capacity (lbs.):

100 (F), 85 (R)

PERFORMANCE

Cruise speed (kts.):

75% power:

197

65% power:

190

55% power:

180

Max range (w/ reserve) (nm):

75% power:

730

65% power:

800

55% power:

828

Fuel consumption (gph):

75% power:

29.0

65% power:

23.3

55% power:

18.7

Estimated endurance (65%) (hrs):

5.5

Stall speed (gear, flaps up) (knots):

65

Stall speed (gear, flaps down) (knots):

61

Best rate of climb (SL fpm):

1550

Best rate of climb, 8000 ft. (fpm):

1250

Max operating altitude (ft.):

25,000

Single-engine service ceiling (ft.):

16,500

Takeoff ground roll (ft.):

1143

Takeoff over 50-ft. obstacle (ft.):

1707

Landing ground roll (ft.):

1400

Landing over 50-ft. obstacle (ft.):

2180
