Piper Geronimo N4411P

Piper Geronimo N4411P

Engine make/model:

Lycoming 0-360-A1D

Horsepower@rpm@altitude:

180@2700@SL

Horsepower for takeoff:

180

TBO hrs.:

2000

Fuel type:

100/100LL

Propeller type:

Hartzell, 2-blade, CS

Landing gear type:

Tri./retr.

Max ramp weight (lbs.):

3800

Empty weight, as tested (lbs):

2423

Useful load, as equipped (lbs.):

1377

Payload, full normal fuel (lbs.):

729

Usable fuel, normal (gals.):

108

Optional fuel (gals.):

156

Oil capacity (qts.):

8

Wingspan:

37 ft.

Overall length:

31 ft. 6 in.

Height:

31 ft. 6 in

Wing area (sq. ft.):

207.6

Wing loading (lbs./sq. ft.):

18.3

Power loading (lbs./hp.):

10.6

Wheel base:

7 ft. 3 in.

Wheel track:

11 ft. 3 in.

Wheel size (in.):

6.00 x 6

Seating capacity:

4-6

Cabin doors:

1

Cabin width (in.):

48

Cabin height (in.):

50

Baggage capacity (lbs./cu. ft.):

200

PERFORMANCE

Cruise speed (kts.):

75% power:

170

60% power:

163

Max range (w/ reserve) (nm):

75% power:

663

60% power:

880

Fuel consumption (gph):

75% power:

18.5

60% power:

17

Estimated endurance (60%) (hrs):

5.5

Vs (kts.):

52

Vs_o(kts.):

47

Best rate of climb (SL fpm):

1500

Best rate of climb,8,000 ft. (fpm):

1000*

Single-engine rate of climb, SL (fpm):

600+*

Service ceiling (ft):

23,000

Single-engine service ceiling (ft.):

12,000

Takeoff ground roll (ft.):

400

Landing ground roll (ft.):

400

Landing over 50-ft. obstacle (ft.):

1400

*estimated

Sources: Aircraft Bluebook Price Digest, Jane's All The World's Aircraft and Pilot's Operating Handbook
